UHF+HF+2.4GHz
Triple Frequency Mobile Data Terminal Super reading distance 50m with 2.4Ghz Active RFID
Barcode
UHF RFID
HF/NFC
Fingerprint
PSAM
Camera
FEATURES
Android 7.0 OS, 4 Core 1.3Ghz Processor
Support 4G, WIFI, Bluetooth, GPS and Camera
2.4Ghz RFID Range Around 50m
5 Inch High-Resolution Screen, Corning Gorilla Third-Generation Touch
Screen Resolution 720* 1280, Visible in the Sun
Barcode, UHF, HF, Fingerprint Functions Optional
Small in Size but Highly Integrated
Related Products
Ci-RF231 Omni-directional Active Reader
Ci-RF231 is omni-directional reader with the …
View Detail
Ci-F286 2.4Ghz Android Active RFID Fixed Reader
Ci-F286 is newly invented active RFID reader …
View Detail
Ci-E262 125Khz LF Activator
Ci-E262 125Khz activator is an important …
View Detail
Ci-RD291 Desktop Active RFID Reader
Ci-RD291 is a destop reader developed specially …
View Detail
Ci-RI265 Long Range Integrated Active RFID Reader
Ci-RI265 is integrated active reader with …
View Detail
Ci-RH272 Active RFID Handheld Reader
- RFID Reader
- Active RFID Reader
- Handheld RFID Reader
- Dual Frequency
- UHF
- 2.4Ghz
- Long Range RFID
- 4G
- SDK-API
- Asset Management
- Distance Measurement
- Waterproof
- Integrated RFID
Ci-RH272 is an industrial android mobile data terminal with high integration of iot functions. The build-in 2.4Ghz active rfid reading distance reach around 50 meters in open area, it is widely used for asset tracking, intelligent transportation, production line management, personnel tracking etc.
Attachment:
Rh272.pdf
FEATURES
Android 7.0 OS, 4 Core 1.3Ghz Processor
Support 4G, WIFI, Bluetooth, GPS and Camera
2.4Ghz RFID Range Around 50m
5 Inch High-Resolution Screen, Corning Gorilla Third-Generation Touch
Screen Resolution 720* 1280, Visible in the Sun
Barcode, UHF, HF, Fingerprint Functions Optional
Small in Size but Highly Integrated
GENERAL PARAMETER
| Cpu | 4 core 64 bit Coretex-A53, 1.3GHz |
| Operation System | Android 7.0 |
| Memory | RAM: 2GB ROM: 16G; support 128GB Micro SD card |
| Screen | 5 inch IPS screen, resolution 720*1280 |
| Touchscreen | Corning Gorilla 3rd generation industrial multi-touch capacitive Screen |
| Expansive | 1 sim card slot, 2 PSAM card slot |
| Communication Port | USB 2.0; 3.5 plug charging port |
| Audio | Support voice broadcast |
| Keyboard | Scan key, function key |
| Gps | Build-in GPS, accuracy±5m |
| Camera | Rear 8 million pixel camera with flash, auto focus function |
COMMUNICATION PARAMETER
| 4g | TD-LTE Band38/39/40/41 | FDD-LTE Band 1, 2, 3, 4, 7, 17, 20 |
| Wifi | 2.4G/5G dual frequency, support IEEE802.11a/b/g/n |
| Bluetooth | Bluetooth 4.0 |
BARCODE PARAMETER (OPTIONAL)
| 1d Barcode Module | Honeywell N431X |
| Support 1d Type | Code 39/Code 93/Code128/Codebar/EAN-13/EAN-8/UPC-A/UPC-E/ITF 14/UCC/EAN-128/ITF25/Matrix 25/EAN-128/ISBN etc |
| 2d Barcode Module | Honeywell-6603 |
| Support 2d Type | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes,US PostNet,US Planet, UK Postal, Australian Postal,Japan Postal, Dutch Postal etc |
FINGERPRINT PARAMETER (OPTIONAL)
| Module Function | Fingerprint capture/contrast/deletion, image processing, etc |
| Sensor | TCSI biometric fingerprint/FBI fingerprint authentication |
| Sensor Type | Capacitive inductance 256 *360pixel, 500 DPI |
| Storage Capacity | 1000pcs |
RFID PARAMETER
| Working Frequency | ISM 2.4-2.48GHz |
| Rf Output | Max+15dBm, step -2dB, software adjustable |
| Receive Sensitivity | -90dBm |
| Antenna | PCB antenna |
| Tag Protocol | Private |
| Reading Distance | 0-80m (open area, tag type matters) |
| Reading Speed | 200pcs/s |
| Api | APK and source code |
UHF RFID(OPTIONAL)
| Working Frequency | 865-868MHz or 902-928MHz |
| Protocol | EPC C1 GEN2 /ISO18000-6C |
| Reading Distance | 4-7m (tag type matters) |
HF RFID(OPTIONAL)
| Working Frequency | 13.56Mhz |
| Protocol | ISO15693/ISO14443 |
MECHANICAL & ELECTRICAL PERFORMANCE
| Dimensions | 170 *85 *23±2mm (Cradle excluded) |
| Weight | 400g default active |
| Battery | 4500mAh Lithium polymer battery (more than 12 hours working time) |
| Power Consumption | 200mw standby, 400mw working |
| Working Temperature | -20°C~+50°C |
| Storage Temperature | -40°C~+70°C |
| Ip Rating | IP66, withstand 1.5m drop |
ACCESSARY
| Standard Accessary | Lithium battery, power adaptor, DC charging cable, USB cable |
| Optional | Bag, cradle |
